Honeywell MS7120 Orbit - Optimal High Density

17
DEPTH OF FIELD BY MINIMUM BAR CODE ELEMENT WIDTH
Optimal High Density
Distance:
Scanner Face
To Bar Code
(mm)
Width of Scan Field (mm)
Minimum Bar Code Element Width
ABCDEFGHJK
mm
.13 .15 .16 .17 .19 .23 .25 .33 .53 .66
mils
5.2 5.7 6.3 6.8 7.5 9 10 13 21 26
B
D
&
0 0
0
&
