Honeywell MS7120 Orbit User Manual

1
INTRODUCTION
Orbit
®
is an aggressive, omnidirectional laser bar code scanner.
Lightweight and rugged, Orbit is small in size, but BIG in performance.
Designed for applications where counter space is limited, Orbit is the
ideal presentation scanner for retail, convenience, liquor and specialty
stores. In addition, Orbit’s unique, contoured shape allows it to be
picked-up and used as a hand-held scanner when scanning large or
bulky items.
Engineered with a large, easy-to-find optimal scan area, Orbit increases
the first pass read rate for maximum productivity. The scanning head can
be tilted vertically a full 30° for added flexibility when scanning various
sized objects. These features increase the scanning throughput without
increasing the scanner size.
SCANNER INTERFACE
7120-00 Laser Emulation, RS-232 Transmit/Receive
7120-9 OCIA and RS-232 Transmit/Receive (Full RS232 Configurable)
7120-11 IBM 46XX and Full RS-232C
7120-41 Full RS-232C/Light Pen Emulation
7120-47
Keyboard Wedge, Stand-Alone Keyboard and RS-232
Transmit/Receive
7120-62 Ruby with Verifone, RS232
7120-67 Full RS-232C (OCIA Configurable)
Orbit offers a great deal of features to the consumer:
• Fully automatic scanning operation
• PowerLink compatible
• Data editing
• 7 beeper tones
• Programmable depth of field
• Easy programming

Honeywell MS7120 Orbit Specifications

General

Light Source	Visible Laser Diode 650 nm ± 10 nm
Print Contrast	35% minimum reflectance difference
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Humidity	5% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Scan Speed	1120 scan lines per second
Interfaces	USB, RS232, Keyboard Wedge, IBM 468x/469x
Power Supply	5 VDC ± 0.25 V
Decode Capability	UPC/EAN, Code 39, Code 128, Interleaved 2 of 5, Codabar, MSI
