Honeywell MS7120 Orbit User Manual

29
DESIGN SPECIFICATIONS
MS7120 SPECIFICATIONS
OPERATIONAL
Light Source: VLD 640-660 nm
Depth of Field: 0 mm to 190 mm (0" to 7.5") at default (programmable)
Scan Speed: 1200 scans/second
Scan Pattern: 5 fields of 4 parallel lines (omnidirectional)
Scan Lines: 20
Min Bar Width: 0.13 mm (5.2 mil)
Decode Capability:
Autodiscriminates all standard bar codes;
for other symbologies call Metrologic
System Interfaces:
PC Keyboard Wedge, RS-232, OCIA, Light Pen Emulation,
IBM 46xx, Stand Alone Keyboard, Laser Emulation, USB
(with an MX009 USB converter cable),
Print Contrast: 35% minimum reflectance difference
Number of
Characters Read:
up to 80 data characters (Maximum number will vary based
on symbology and density)
Roll, Pitch, Yaw: 360°, 60°, 60°
Beeper Operation: 7 tones or no beep
Indicators (LED):
Green* = laser on, ready to scan * Indicator colors
Red* = good read, decoding can be reversed
MECHANICAL
Height: 150 mm (5.9")
Depth: 105 mm (4.1")
Width-Orb: 80 mm (3.1")
Width-Base: 102 mm (4.0")
Weight: 380 grams (13.4 oz.)
Termination: 10-pin modular RJ45
Cable:
Standard 2.1 m (7') straight;
Optional 2.7 m (9') coiled cable
Tilt - Orb: 30° vertical
Continued next page

Honeywell MS7120 Orbit Specifications

General

Light Source	Visible Laser Diode 650 nm ± 10 nm
Print Contrast	35% minimum reflectance difference
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Humidity	5% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Scan Speed	1120 scan lines per second
Interfaces	USB, RS232, Keyboard Wedge, IBM 468x/469x
Power Supply	5 VDC ± 0.25 V
Decode Capability	UPC/EAN, Code 39, Code 128, Interleaved 2 of 5, Codabar, MSI
