Honeywell MS7120 Orbit User Manual

20
DEPTH OF FIELD BY MINIMUM BAR CODE ELEMENT WIDTH
Far
Distance:
Scanner Face
To Bar Code
(mm)
Width of Scan Field (mm)
Minimum Bar Code Element Width
ABCDEFGHJK
mm
.13 .15 .16 .17 .19 .23 .25 .33 .53 .66
mils
5.2 5.7 6.3 6.8 7.5 9 10 13 21 26
0
00
0
D
&

Honeywell MS7120 Orbit Specifications

General

Light Source	Visible Laser Diode 650 nm ± 10 nm
Print Contrast	35% minimum reflectance difference
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 60°C (-40°F to 140°F)
Humidity	5% to 95% relative humidity, non-condensing
Scan Pattern	Omnidirectional
Scan Speed	1120 scan lines per second
Interfaces	USB, RS232, Keyboard Wedge, IBM 468x/469x
Power Supply	5 VDC ± 0.25 V
Decode Capability	UPC/EAN, Code 39, Code 128, Interleaved 2 of 5, Codabar, MSI
