• Functioning temperature: - 5° C - + 40° C.
• Relative humidity: 10 % - 93 % (without condensate).
• Storage temperature: - 10° C - + 50° C.
• Weight : 2 Kg
 Earth connecting
The earth connecting has to be realized in accordance with the CEI and ISPELS rules with a resistance
lower than 10 Ohm. It is mandatory to connect the earth cable to the control panel on the CNAL terminal.
 Primary supply
In normal condition the control panel is powered from the mains voltage line.
In case of mains loss, stand-by power is provided from the rechargeable batteries.
The requested characteristics for the mains supply voltage are:
• Voltage: 230 V ac single-phase + 10%, - 15%.
• Frequency: 50 / 60 Hz.
• Electrical input: 0.45 A.
%
NOTE: It is necessary to take care when the installation is near powerful
electromagnetic sources (radio equipments, electric motors, etc.).
 Power supply
The power supply provide the following outputs:
• 27.6 Vdc + 2 % - 10 % 1 A ripple max. 300 mV (Supply set for the control panel, user output,
external load factors and extinguishing board).
• 27.6 Vdc / 0.45 A: Battery-charge for batteries.
 Battery-charge section
• Output voltage = 27.6 Vdc.
• Electrical output = 0.45 A ~ 100 mVpp max (temperature compensation).
• Number of batteries that can be connected= 2 * 12 V, 7 Ah.
Battery Yuasa NP7-12 type or NP7-12FR (UL94) Faston - Capacity (20hr) = 12 V 7 Ah –
Dimensions = 151(b) x 65 (p) x 98 (h).
Battery Fiamm FG20721 type or FGV20721 (UL94) Faston - Capacity (20hr) = 12 V 7.2 Ah –
Dimensions = 151(b) x 65 (p) x 98 (h).
• The battery-charge section has the following signalization threshold:
Exhausted battery = 21.5 Vdc.
In balance of the re-charge= 3.4 Vdc (voltage difference between 2 batteries)
Battery release = 20 Vdc.
• Standby absorption without 230 Vac Network voltage: 90 mA without optional board.
 List of the fuses
• On the 230 V Network voltage = 2 A FAST.
• On the siren output= 0.75 A to be restored.
• On the battery input= 2.5 to be restored.
• On the user output= 1 A FAST.
