PAGE - 6 Installation Manual AM-1000
NOTIFIER ITALIA Doc. M-145.1-AM1000-ENG Rev A.2 AM1000_manu
C
C
O
O
M
M
P
P
O
O
N
N
E
E
N
N
T
T
S
S
O
O
F
F
T
T
H
H
E
E
S
S
Y
Y
S
S
T
T
E
E
M
M
Lines for the communication to detectors/modules
The AM1000 control panel interacts with the detection devices and intelligent/addressable devices through a
2 cable line.
The line can be connected in the way to respect the specifications related to the STYLE 4 (open line) and
STYLE 6 (closed line) signalization circuits lines.
The peripheral devices are supplied through the same line used to communicate with them.
If a line is connected to more than 32 devices (ref. EN54.2) it has to be STYLE 6 configured (closed line).
Isolator modules
The isolator modules (ISO-X) allow the electrical isolation of some devices from others on the same loop,
this permit to critical components on the loop to function even in case of short-circuit on the communication
line.
Input modules
The addressable modules (MMX) permit to the AM1000 control panel the control of the N.A. contacts,
manual alarm buttons, fire detectors with 4 conventional wires, thermal detectors, humidity detectors and
devices for the supervision.
Output modules
Thanks to the output modules (CMX) the AM1000 control panel, through programmable CBE equations, can
activate indication circuits or output relays with contact free from potential.
Intelligent detectors
The AM1000 control panel can communicate with ionic analog, photoelectric, thermal and rate of rise
detectors.
Technical information regarding the connection of cables for analog line
Type of cable: twisted (5cm.) and screened with 2 conductors.
Sections referring to the total length of the line (in case of “STYLE 6” loop so closed loop, we consider the
length of the ring) however it has not to exceed a total of 3000 meters and the total resistance of the line has
to be lower than 40 Ohm.
Schedule of the minimum necessary sections compared with the length the line
Up to 1.000 meters cable 2 x 1 mm² 16 AWG Belden 9575
Up to 1.500 meters cable 2 x 1.5 mm² 16 AWG Belden 9575
Up to 2.000 meters cable 2 x 2 mm² 14 AWG Belden 9581
Up to 3.000 meters cable 2 x 3 mm² 12AWG Belden 9583
