AM-1000 Installation manual PAGE - 3
AM1000_manu Doc. M-145.1-AM1000-ENG Rev A.2 NOTIFIER ITALIA
Number of devices to be installed on the line
The maximum number of devices that can be connected on the detection line is
the following:
• 99 detectors
• 99 input/output modules
Features of the output relays
CN0 terminal board
N° Description Features Notes
21
RL NA-NC Alarm
20
RL Common Alarm
1A 30Vdc contact
NA-NC selectable by
JALL jumper
19
RS232 GND
18
RS232 RI
17
RS232 RX
16
RS232 RTS
15
RS232 RTX
Non opto-isolated serial output (if the
connected devices have the negatives
earthing will appear the signal “ Earth
Trouble” ).
14
GND User
13
+24Vdc User
Protected by 1A Fast fuse
12
RL Negative Siren
11
RL Positive Siren
Protected by 0,75A fuse
(polarity inversion output).
Current at disposal of the
user (sum of the two
outputs).
10
RL Common trouble
9
RL NA-NC trouble
1A 30Vdc contact
NA-NC to be select
through JGST jumper.
8
GNDI
7
RS485 LIN-
6
GNDI
5
RS485 LIN+
Opto-isolated serial output
Available function with
the insertion of the
optional AM1SE board.
4
Line 1 B-
3
Line 1 B+
2
Line 1 A-
1
Line 1 A+
LINE 1
FUNCTION
Siren
General alarm
General trouble
FEATURES
1 24 Vdc / 1 A supervised contact.
Max 1 A 30Vdc , NA-NC selectable by JALL jumper
Max 1 A 30Vdc , NA-NC selectable by JGST jumper
