ID3000/ID2000 Fire Panel Configuration Tool Manual
Network
6 - 10 997-291, Version 3.05
November 2010
Number of zones on network
There are two types of zone numbering available
on the ID
2
net, available in both Standard and
VdS modes:
a. Local.
b. Network.
Local
The maximum number of zones on a network
is: 32 panels x 255 zones per panel = 8160.
The zones are numbered in the range 1 to 255
for each panel.
If zone indicator lamps are fitted, they only
indicate the status of that panel’s zones.
Network
The maximum number of zones on a network
is 8160, made up as described for Local.
However, the zones are numbered in the range
1 to 8192 across the network. Each number
must be unique across the network. The panel
has an internal software table which maps the
network zone number to its internal zone
number (1 to 255).
If zone indicator lamps are fitted, they indicate
the status of the network zone numbers up to
a maximum of 256; higher numbers are NOT
indicated.
