ID3000/ID2000 Fire Panel Configuration Tool Manual
Network
6 - 16 997-291, Version 3.05
November 2010
Supervisor View
This window does not contain any sector
information as all network nodes are allocated
initially to one sector, i.e. Sector 1 and no
supervisor panels have been assigned. To assign
a panel as a supervior, simply select the panel
and, holding down the left mouse button, drag
the node across to the Supervisor View window.
In the example above, ‘Main Building’ panel in
Sector 1 has now been assigned to the network
with supervisor status. Repeat this procedure for
all other panels that are to have supervisor status.
If the wrong panel was dragged across select
<CANCEL>, or right-click on the unwanted
supervisor panel and select ‘Remove Supervisor’
to delete it from the Supervisor View window.
This will not remove it from the Network.
