Honeywell PW6K1ICE User Manual

8 www.honeywell.com
PW6K1ICE Wiring and Setup
PW6K1ICE Hardware
2.1 PW6K1ICE Hardware
Figure 2-1: PW6K1ICE Control Board
Figure 2-2: PW6K1ICE Control Board Solder Side
TB1 TB2 TB3
11 1
12V
PoE
J3
TB5
1
TB4
1
3
4
S1
2
1
ON
S2
7654321
J7
J1
J4
J5
BT1
K1
J6
K2
TB1
TB5
RESET SWITCH
.15 [3.81] 2.55 [64.77] 2.55 [64.77] .15 [3.81]
.20 [5.08]
5.40 [137.16]
2.35 [59.69]
.20 [5.08]
2.75 [69.85]
TAMPER
SWITCH
CONNECTION
(J7)
ETHERNET
CONNECTOR
(J6)
PoE/12Vdc
POWER SELECTOR
JUMPER (J3)
DIP SWITCHES STATUS LEDs
SOLDER SIDE
RELAY K1 LED
RELAY K2 LED
