22 www.honeywell.com
PW6K1ICE System Configuration via Web Interface
Overview
3.1 Overview
PW6K1ICE comes with Access Control Device Server Manager (ACDSM); i.e., a
built-in web server through which the users can configure their network and other
system settings.
Note: The default factory-set TCP/IP address for the built-in system configuration web
server is 192.168.0.251
3.1.1 Connecting to ACDSM for the First Time
1. Use the factory default controller IP address 192.168.0.251.
2. Set the DIP switches to S4=OFF, S3=OFF, S2=ON, S1=ON.
3. Connect the computer to host the web server via Ethernet Port 0. Connection
should be via crossover Ethernet cable or by the regular Ethernet cables
connected via the hub.
4. Set the host computer to the static IP address 192.168.0.250 to be able to
connect to the factory-default PW6K1ICE controller at address 192.168.0.251.
5. Power up the PW6K1ICE controller.
