18 www.honeywell.com
PW6K1ICE Wiring and Setup
Additional Mounting Information
2.15 Additional Mounting Information
Sources for the optional items are shown below:
• 3-gang stainless steel blank cover: Leviton part number 84033-40. Available
from Graybar, part number 88158404.
• Magnetic switch set: G.R.I. part number: 505.
Humidity • 10 to 95% RHNC
Mechanical
Dimensions • 5.4" (140mm)W x 2.75" (70mm)L x 0.96"
(24mm)H without bracket
• 5.5" (140mm)W x 3.63" (92mm)L x 1.33"
(34mm)H with bracket
Weight • 3.8 oz. (106.35g) without bracket
• 4.7 oz. (133.28g) with bracket
Enclosure
Box type • The unit must be installed within a UL
514A/UL 514C Listed (QCIT or QCMZ) 3-
gang electrical box.
Box dimensions • The minimum dimensions for the electrical
box are 2.75 inches by 2.75 inches by 5.8
inches, with a minimum capacity of 44
cubic inches.
Box spacing • Minimum spacings must be enforced of at
least 1/2 inch between the PWB/
components and the enclosure.
Tamper switch • For UL applications, a tamper switch must
be installed.
