PW6K1ICE Wiring and Setup
Terminal Connections
PW6K1ICE Installation and Configuration Guide, Document 800-07985V1, Revision A 9
2.2 Terminal Connections
Table 2-1: PW6K1ICE Terminal Connections
Terminal Acronym Description
TB1-1 IN1 Input 1
TB1-2 IN1
TB1-3 IN2 Input 2
TB1-4 IN2
TB2-1 VO Reader 1 Power Output - 12VDC
TB2-2 LED Reader 1 LED Output
TB2-3 BZR Reader 1 Buzzer Output
TB2-4 CLK Reader 1 CLK/Data 1/TR+
TB2-5 DAT Reader 1 DAT/Data 0/TR-
TB2-6 GND Reader 1 Ground
TB3-1 LED Reader 2 LED Output
TB3-2 BZR Reader 2 Buzzer Output
TB3-3 CLK Reader 2 CLK/Data 1 Input
TB3-4 DAT Reader 2 DAT/Data 0 Input
TB4-1 VO Auxiliary Power Output - 12VDC
TB4-2 GND Auxiliary Power Output Ground
TB4-3 VIN Input Power - 12VDC (from local power supply)
TB4-4 GND Input Power Ground
TB5-1 NO Relay K1 - Normally Open Contact
TB5-2 1-C Relay K1 - Common Contact
TB5-3 NC Relay K1 - Normally Closed Contact
TB5-4 NO Relay K2 - Normally Open Contact
TB5-5 2-C Relay K2 - Common Contact
TB5-6 NC Relay K2 - Normally Closed Contact
