Specifications
PW6K1ICE Installation and Configuration Guide, Document 800-07985V1, Revision A 17
Inputs • 2 supervised, Programmable End of Line resistors, 1k/2k - ohm 1%
1/4W watt standard, and dedicated tamper input
Relays • 2 outputs, Form-C contacts: 2A @ 30VDC
Reader Interface
Reader Power: • 12VDC 10% or local power supply
(12VDC) (PTC limited 150mA max)
Reader Data Inputs • Two TTL reader ports or one 2-wire RS-485
reader port capable of supporting two
readers
RS-485 Mode • 9600 bps
• Asynchronous
• Half-duplex
•1 start bit
• 8 data bits
• 1 stop bit
• Maximum cable length: 4000' (1,200m)
LED Output • TTL compatible
• High > 3V
• Low < 0.5V
• 5mA source/sink maximum
Buzzer Output • Open collector
• 5VDC open circuit maximum
• 10mA sink maximum
Cable requirements
Power • 1 twisted pair, 18 AWG
Ethernet • CAT-5 (minimum)
RS-485 • 24AWG, 4,000ft (1,200m) maximum
• Twisted pair(s) with an overall shield
Alarm Input • 1 twisted pair per input
• 30-ohm maximum loop resistance
Reader data
(TTL)
•18AWG
• 6 conductors
• 500-foot (150 m) maximum
Reader data
(RS-485)
•24AWG
• 120-ohm impedance
• Twisted pair with shield
• 4000-foot (1,219 m) maximum
Environmental
Temperature • 0 to 70°C, operating
• -55 to +85°C, storage
