31-00400M-01 | Rev10-20 11
DIMENSIONS
• Swipe: Quickly slide one or more fingers across the screen to reveal controls or to
scroll through lists or groups of items; equivalent to scroll.
Figure 1 Hand Gestures Convention
• A green tick appears before the valid selection
• If the option selected or the text entered is valid, the option to move to the
subsequent screen turns blue. Tapping the option in blue will toggle to next
screen.
Dimensions
Figure 2 Dimensions
Swipe right to view or
scroll towards left
Swipe down to view
or scroll towards up
Swipe up to view or
scroll towards down
Tap to select an item
Swipe left to view or
scroll towards right
3 -19/32 ” (91.2 mm)
4 - 15/32”
(113.7 mm)
4 x 11/32”
(9mm)
2 - 3/8”
(60.3mm)
3 - 1/4”
(82.75mm)
4 x 3/16”
(4.5mm)
