18 31-00400M-01 | Rev10-20
2 - GETTING STARTED
Home Page (Main Screen): Temperature reading and adjustment
Table 8 Home Page (main screen) overview
Serial
Number
Description
1 Indoor Humidity: Displays the current indoor humidity
2 Current Priority: Tap to toggle between occupied or unoccupied mode
3 Indoor Temperature: Displays the current indoor temperature.
4 Mode Display: Orange flame for heat mode, blue snowflake for cool mode.
5 Wi-Fi signal strength
6 Time
7 Adjust temperature: Touch the up arrow to increase the desired temperature.
8 Desired temperature: Displays the desired temperature.
9 Adjust temperature: Touch the down arrow to decrease the desired temperature.
10 Temperature Slider: Use finger to move the slider to set the desired temperature.
11 Page Slider: Use finger to slide to left or right to display more options.
