Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
101 63-4528—04
Basic Parameter
Table 2. Basic Parameter
Parameter Explanation Settings
Factory
Setting
01-00 Max. Operating Frequency (Hz)
50.00~600.00Hz
60.00
01-01 Motor1: Max Output Frequency(Hz)
0.00~600.00Hz
60.00
01-02 Motor1: Max Output Voltage (V)
230V: 0.0V~255.0V
460V: 0.0V~510.0V
230.0
460.0
01-03 Mid-point Frequency 1 of Motor 1
0.00~600.00Hz
3.0
a
01-04 Mid-point Voltage 1 of Motor 1
230V: 0.0V~240.0V
460V: 0.0V~480.0V
11.0
22.0
01-05 Mid-point Frequency 2 of Motor 1
0.00~600.00Hz
0.50
a
01-06 Mid-point Voltage 2 of Motor 1
230V: 0.0V~240.0V
460V: 0.0V~480.0V
2.0
8.0
01-07 Min. Output Frequency of Motor 1
0.00~600.00Hz
0.00
a
01-08 Min. Output Voltage of Motor 1
230V: 0.0V~240.0V
460V: 0.0V~480.0V
0.0
0.0
01-09 Start-Up Frequency
0.00~600.00Hz
0.50
a
01-10 Output Frequency Upper Limit 0.00~600.00Hz 600.00
a
01-11 Output Frequency Lower Limit 0.00~600.00Hz 0
a
01-12 Accel. Time 1
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
Frame
A,B,C: 30.00
Frame D,E:
60.00
a
01-13 Decel. Time 1
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
30.00
10.0
a
01-14 Accel. Time 2
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-15 Decel. Time 2
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-16 Accel. Time 3
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-17 Decel. Time 3
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-18 Accel. Time 4
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-19 Decel. Time 4
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-20 JOG Acceleration Time
Pr.01-37=0: 0.00~600.00 second
Pr
.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-21 JOG Deceleration Time
Pr.01-37=0: 0.00~600.00 second
Pr.01-37=1: 0.0~6000.0 second
10.00
10.0
a
01-22 JOG Frequency 0.00~600.00Hz 6.00
a
01-23
Frequency of 1st Acceleration /
Deceleration & Frequency of 4th
Acceleration / Deceleration.
0.00~600.00Hz
0.00
a
01-24 S-curve Time 1
Pr.01-37=0: 0.00~25.00 second
Pr.01-37=1: 0.0~250.0 second
0.20
0.2
