CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
63-4528—04 102
Digital Input/Output Parameters
Table 3. Digital Input/Output Parameters
a
01-25 S-curve Time 2
Pr.01-37=0: 0.00~25.00 second
Pr.01-37=1: 0.0~250.0 second
0.20
0.2
a
01-26 S-curve Time 3
Pr.01-37=0: 0.00~25.00 second
Pr.01-37=1: 0.0~250.0 second
0.20
0.2
a
01-27 S-curve Time 4
Pr.01-37=0: 0.00~25.00 second
Pr.01-37=1: 0.0~250.0 second
0.20
0.2
01-28 Skip Frequency 1 Upper Limit
0.00~600.00Hz
0.00
01-29 Skip Frequency 1 Lower Limit
0.00~600.00Hz
0.00
01-30 Skip Frequency 2 Upper Limit
0.00~600.00Hz
0.00
01-31 Skip Frequency 2 Lower Limit
0.00~600.00Hz
0.00
01-32 Skip Frequency 3 Upper Limit
0.00~600.00Hz
0.00
01-33 Skip Frequency 3 Lower Limit
0.00~600.00Hz
0.00
01-34 Zero-speed Mode
0: Output waiting
1: Zero-speed operation
2: Output at Minimum Frequency (the 4
th
output
frequency)
0
01-35 V/f Curve Selection
0: normal V/F curve
1: Curve to the power of 1.5
2: Curve to the power of 2
2
a
01-36
Optimal Acceleration/Deceleration
Setting
0: Linear accel. /decel.
1: Auto accel., Linear decel.
2: Linear accel., Auto decel.
3: Auto accel. / decel.
4: Linear, stall prevention by auto accel./decel.
(limit by Pr.01-12 to 01-21)
0
01-37
Time Unit for Accel. /Decel. and S
Curve
0: Unit: 0.01 sec
1: Unit: 0.1sec
0
Parameter Explanation Settings
Factory
Setting
02-00 2-wire/3-wire Operation Control
0: 2-wire mode, power on for operation control
1: 2-wire mode 2, power on for operation control
2: 3-wire, power on for operation control
1
Table 2. Basic Parameter
Parameter Explanation Settings
Factory
Setting
