CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
63-4528—04 104
a
02-11 Multi-function Input Response Time
0.000~30.000 seconds
0.005
a
02-12 Multi-function Input Mode Selection 0~65535, 0: N.O., 1: N.C., error 0
a
02-13 RLY1: Multi Output Terminal 0: No function
1: Operation Indication
2: Operation speed attained
4: Desired frequency attained 2 (Pr.02-22)
5: Zero speed (Frequency command)
6: Zero speed, include STOP(Frequency command)
7: Over torque 1
8: Over torque 2
9: Drive is ready
10: Low voltage warning (LV): (Pr.06-00)
11: Malfunction indication
12: Mechanical brake release (Pr.02-30)
13: Overheat warning (Pr.06-14)
14: Software brake signal indication (Pr.07-00)
15: PID feedback error
16: Slip error (oSL)
17: Terminal count value attained, does not return to 0
(Pr.02-18)
18: Preliminary count value attained, returns to 0
(Pr.02-17)
19: Base mask
20: Warning output
21: Over voltage warning
22: Over-current stall prevention warning
23: Over-voltage stall prevention warning
24: Operation mode indication
25: Forward command
26: Reverse command
27: Output when current >= Pr.02-31 (>= 02-31)
28: Output when current <=Pr.02-31 (<= 02-31)
29: Output when frequency >= Pr.02-32 (>= 02-32)
30: Output when frequency <= Pr.02-32 (<= 02-32)
31: Y-connection for the motor coil
32: D-connection for the motor coil
33: Zero speed (actual output frequency)
34: Zero speed include stop(actual output frequency)
35: Error output selection 1(Pr.06-22)
36: Error output selection 2(Pr.06-23)
37: Error output selection 3(Pr.06-24)
38: Error output selection 4(Pr.06-25)
40: Speed attained (including Stop)
44: Low current output
45: UVW Magnetic Contactor enabled
47: Brake output closed
50: Output for CANopen control
51: Output for RS485
52: Output for communication card
53: Fire mode indication
54: Bypass fire mode indication
55: Motor #1 Output
56: Motor #2 Output
57: Motor #3 Output
58: Motor#4 Output
59: Motor#5 Output
60: Motor #6 Output
61: Motor#7 Output
62: Motor#8 Output
11
a
02-14 RLY2: Multi Output Terminal 1
a
02-15 RLY3: Multi Output Terminal 9
a
02-34
Expansion Card Output Terminal
(MO3)
0
a
02-35
Expansion Card Output Terminal
(MO4)
0
a
02-36
Expansion Card Output Terminal
(MO5)
0
a
02-37
Output terminal of the I/O extension
card (MO6)
0
a
02-38
Output terminal of the I/O extension
card (MO7)
0
a
02-39
Output terminal of the I/O extension
card (MO8)
0
a
02-40
Output terminal of the I/O extension
card (MO9)
0
a
02-41
Output terminal of the I/O extension
card (MO10)
0
a
02-42
Output terminal of the I/O extension
card (MO11)
0
a
a
02-43
Output terminal of the I/O extension
card (MO12)
0
02-44
Output terminal of the I/O extension
card (MO13)
0
a
02-16 Multi-function output direction 0~65535, 0: N.O., 1: N.C. 0
a
02-17 Terminal counting value attained 0~65500 0
Parameter Explanation Settings
Factory
Setting
