Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
105 63-4528—04
a
02-18
Preliminary counting value attained
(not return to 0)
0~65500
0
a
02-19 Digital Output Gain (DFM) 1~166 1
a
02-20 Desired Frequency Attained 1
0.00~600.00Hz 60.00/
50.00
a
02-21
The Width of the Desired Frequency
Attained 1
0.00~600.00Hz
2.00
a
02-22 Desired Frequency Attained 2
0.00~600.00Hz 60.00/
50.00
a
02-23
The Width of the Desired Frequency
Attained 2
0.00~600.00Hz
2.00
02-30 Brake Delay Time
0.000~65.000
0.000
a
02-31
Output Current Level Setting for Multi-
function External Terminals
0~100%
0
a
02-32
Output frequency setting
for multi-function output
terminal
0.00~600.00Hz
0.00
a
02-33
External Operation Control Selection
after Reset and Activate
0: Disabled
1: Drive runs if run command exists after reset
1
a
02-45 Max. Frequency of Resolution Switch 0.01~600.00Hz 60.00
a
02-46
Switch the delay time of Max. output
frequency
0.000~65.000 seconds
0.000
a
02-47 Status of Multi-function Input Terminal Monitor the status of multi-function input terminals
Read
Only
a
02-48
Status of Multi-function Output
Terminal
Monitor the status of multi-function output terminals
Read
Only
02-49
Display External Output terminal
occupied by PLC
Monitor the status of PLC input terminals
Read
Only
02-50
Display Analog Input Terminal
occupied by PLC
Monitor the status of PLC output terminals
Read
Only
02-51
Display the Frequency Command
Memory of External Terminal
Read Only
Read
Only
02-52
Mix active by Internal or External
Selection
0~65535 0
02-53 Internal Mix active value 0~65535 0
Parameter Explanation Settings
Factory
Setting
