Analog Input/Output Parameter
Table 4. Analog Input/Output Parameter
Parameter Explanation Settings
Factory
Setting
a
03-00 Analog Input 1 (AVI1)
0: No function
1: Frequency command
4: PID target value
5: PID feedback signal
6: PTC thermistor input value
11: PT100 thermistor input value
12~17: Reserved
03-00:1
03-01:0
03-02:0
a
03-01 Analog Input 2(ACI)
a
03-02 Analog Input 3 (AVI2)
a
03-03 AVI1 Analog Input Bias -100.0~100.0% 0
a
03-04 ACI Analog Input Bias -100.0~100.0% 0
a
03-05
AVI2 Analog Positive Voltage Input
Bias
-100.0~100.0%
0
a
03-06 AVI1 positive/negative bias mode 0: No bias
1: Lower than bias=bias
2: Greater than bias=bias
3: The absolute value of the bias voltage
while serving as the center
4: Serve bias as the center
0
a
03-07 ACI positive/negative bias mode
a
03-08 AVI2 positive/negative bias mode
a
03-09 Analog Input Gain 1 (AVI1)
-500.0~500.0%
-500.0~500.0%
-500.0~500.0%
100.0
100.0
100.0
a
03-10 Analog Input Gain 2 (ACI)
a
03-11 Analog Positive Input Gain 3 (AVI2)
a
03-12 Analog Input Filter Time (AVI1) 0.00~20.00 seconds 0.01
a
03-13 Analog Input Filter Time (ACI) 0.00~20.00 seconds 0.01
a
03-14 Analog Input Filter Time (AVI2) 0.00~20.00 seconds 0.01
a
03-15 Addition Function of the Analog Input
0: Disable addition function (AVI1, ACI, AVI2)
1: Enable addition function
0
a
03-16 Loss of the ACI Signal
0: Disable
1: Continue operation at the last frequency
2: Decelerate to 0Hz
3: Stop immediately and display ACE
0
a
03-17 Multi-function Output 1 (AFM1) 0: Output frequency (Hz) 0
03-18 Gain for Analog Output 1 (AFM1)
0~500.0%
100
03-19
Analog Output 1 Value in REV
Direction (AFM1)
0: Absolute output voltage
1: Reverse output 0V; Positive output 0-10V
2: Reverse output 5-0V; Positive output 5-10V
0
