CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
63-4528—04 108
Multi-step Speed Parameters
03-40 ACI Point 1- Hz 0.00 ~ 600.00Hz 20.00
03-41 ACI Point 2 – V/mA 0.00 ~ 10.00 / 0.00~20.00 10.00/20.00
03-42 ACI Point2 - Hz 0.00 ~ 600.00 Hz 60.00
03-43 ACI Point 3 – V/mA 0.00 ~ 10.00 / 0.00~20.00 10.00/20.00
03-44 ACI Point3 - percent 0.00 ~ 600.00Hz 60.00
03-45 AUI Point1 - voltage 0.00~10.00V 0.00
03-46 AUI Point 2- percent 0.00 ~ 600.00Hz 0.00
03-47 AUI Point 2- voltage 0.00~10.00V 10.00
03-48 AUI Point2 - Hz 0.00 ~ 600.00Hz 0.00
03-49 AUI Point 3- voltage 0.00~10.00V 10.00
03-50 AUI Point 3 - Hz 0.00~600.00Hz 60.00
Table 5. Multi-step Speed Parameters
Parameter Explanation Settings
Factory
Setting
a
04-00 1st Step Speed Frequency 0.00~600.00Hz 30.00
a
04-01 2nd Step Speed Frequency 0.00~600.00Hz 40.00
a
04-02 3rd Step Speed Frequency 0.00~600.00Hz 5.5
a
04-03 4th Step Speed Frequency 0.00~600.00Hz 50.00
a
04-04 5th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-05 6th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-06 7th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-07 8th Step Speed Frequency 0.00~600.00Hz 60.00
a
04-08 9th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-09 10th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-10 11th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-11 12th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-12 13th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-13 14th Step Speed Frequency 0.00~600.00Hz 5.5
a
04-14 15th Step Speed Frequency 0.00~600.00Hz 5.5
Table 4. Analog Input/Output Parameter
Parameter Explanation Settings
Factory
Setting
