Honeywell VFD CORE

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
109 63-4528—04
Motor Parameters
Table 6. Motor Parameters
Parameter Explanation Settings
Factory
Setting
05-00 Motor Auto Tuning
0: No function
1: Measure induction motor in dynamic status (motor
spinning) (Rs, Rr, Lm, Lx, no-load current)
2: Measure induction motor in static status (motor not
spinning)
0~10
0
05-01
Full-Load current of
Induction Motor 1 (Amps)
10~120% of the drive’s rated current
###.##
a
05-02
Rated Power of Induction
Motor 1 (kW)
0~655.35kW
###.##
a
05-03
Rated Rotational Speed of
Induction Motor 1 (rpm)
0~65535
1710 (60Hz 4 poles): 1410 (50Hz 4 poles)
1710
05-04
Pole Number of Induction
Motor 1
2~20
4
05-05
No Load Current of
Induction Motor 1 (Amps)
0~ Pr.05-01 of factory setting
###.##
05-06
Accumulated Motor
Operation Time (minutes)
00~1439
0
05-07
Accumulative Motor
Operation Time (day)
00~65535
0
