Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
111 63-4528—04
a
06-14
Heat Sink Over-heat
(OH1) Warning
0.0~110.0
85.0
a
06-15
Stall Prevention Limit
Level
0~100% (Parameter06-02?Parameter06-03)
50
06-16 Current Error Record
0: No fault record
1: Over-current during acceleration (ocA)
2: Over-current during deceleration (ocd)
3: Over-current during constant speed(ocn)
4: Ground fault (GFF)
5: IGBT short-circuit (occ)
6: Over-current at stop (ocS)
7: Over-voltage during acceleration (ovA)
8: Over-voltage during deceleration (ovd)
9: Over-voltage during constant speed (ovn)
10: Over-voltage at stop (ovS)
11: Low-voltage during acceleration (LvA)
12: Low-voltage during deceleration (Lvd)
13: Low-voltage during constant speed (Lvn)
14: Stop mid-low voltage (LvS)
15: Phase loss protection (PHL)
16: IGBT over-heat (oH1)
17: Capacitance over-heat (oH2) (over 40hp)
18: tH1o (TH1 open: IGBT over-heat
protection error)
19: tH2o (TH2 open: capacitance over-heat
protection error)
20: Reserved
21: Drive over-load (oL) (When current is 150% of the
rated current, the drive will be overloaded.)
22: Electronics thermal relay 1 (EoL1)
23: Electronics thermal relay 2 (EoL2)
24: Motor overheat (oH3) (PTC)
25: Reserved
26: Over-torque 1 (ot1)
27: Over-torque 2 (ot2)
28: Under current 1 (uc1)
29: Reserved
30: Memory write-in error (cF1)
31: Memory read-out error (cF2)
32: Reserved
33: U-phase current detection error (cd1)
34: V-phase current detection error (cd2)
35: W-phase current detection error (cd3)
36: Clamp current detection error (Hd0)
37: Over-current detection error (Hd1)
38: Over-voltage detection error (Hd2)
39: Ground current detection error (Hd3)
40: Auto tuning error (AuE)
41: PID feedback loss (AFE)
42~47 Reserved
48: ACI reference input loss (ACE)
49: External fault input (EF)
50: Emergency stop (EF1)
82
06-17
Second Most Recent Error
Record
82
06-18
Third Most Recent Error
Record
82
06-19
Fourth Most Recent Error
Record
82
06-20
Fifth Most Recent Error
Record
82
06-21
Sixth Most Recent Error
Record
84
a
06-22 Fault Output Option 1 0~65535(refer to bit table for fault code) 0
a
06-23 Fault Output Option 2 0~65535(refer to bit table for fault code) 0
a
06-24 Fault Output Option 3 0~65535(refer to bit table for fault code) 0
Table 7. Protection Parameters
Parameter Explanation Settings
Factory
Setting
