Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
63-4528—04 112
a
06-25 Fault Output Option 4 0~65535(refer to bit table for fault code) 0
a
06-26 PTC Detection Selection
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
0
a
06-27 PTC Level 0.0~100.0% 50.0
a
06-28
Frequency Command
when Malfunction
0.00~655.35 Hz 60.00
Read Only
06-29
Output Frequency when
Malfunction
0.00~655.35 Hz 1.31
Read Only
06-30
Output Voltage when
Malfunction
0.0~6553.5 V 0.1
Read Only
06-31 DC Voltage at Malfunction
0.0~6553.5 V Read Only
06-32
Output Current at
Malfunction
0.00~655.35 Amp Read Only
06-33
IGBT Temperature at
Malfunction
0.0~6553.5 Read Only
06-34
Capacitance Temperature
at Malfunction
0.0~6553.5 Read Only
06-35
Motor Speed in rpm at
Malfunction
0~65535 Read Only
06-36
Status of Multi-function
Input Terminal when
Malfunction
0~65535 Read Only
06-37
Status of Multi-function
Output Terminal when
Malfunction
0~65535 Read Only
06-38
Drive Status when
Malfunction
0~65535 Read Only
06-39
Action for detected Output
Phase Loss (OPhL)
0: Warn and keep operation
1: Warn and ramp to stop
2: Warn and coast to stop
3: No warning
3
06-40
Time of detected Output
Phase Loss
0~65.535 seconds
0.5
06-41
Detected Current
Bandwidth
0~655.35%
1.0
06-42
DC Brake Time of Output
Phase Loss
0~65.535 seconds
0.1
06-43
Time of detected Input
Phase Loss
0.00~600.00 seconds
0.20
06-44
Ripple of the detected
Input Phase Loss’ Ripple
230V: 0.0 ~ 160 Vdc
460V: 0.0 ~ 320 Vdc
30/60
06-45
Action for detected Input
Phase Loss (OrP)
0: warn and ramp to stop
1: warn and coast to stop
0
Table 7. Protection Parameters
Parameter Explanation Settings
Factory
Setting
