Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
113 63-4528—04
06-46 Derating Protection
0: Constant rated current and limit carrier wave by loaded
current and temperature
1: Constant carrier frequency and limit loaded current by
setting carrier wave
2: Constant rated current(same as setting 0), but current
limit is closed
0
06-47 PT100 Detection Level 1 0.000~10.000 v 5.000
06-48 PT100 Detection Level 2 0.000~10.000 v 7.000
06-49
PT100 Level 1 Frequency
Protect
0.00~600.00 Hz 0.00
06-50
Software Detection GFF
Current Level (% rated
current of the drive)
0~6553.5% 60.0
06-51
Software detection of GFF
Low pass Filter gain
0~655.35 sec 0.10
06-52 Disable Level of dEb
230V: 0~220.0 Vdc
460V: 0~440.0 Vdc
180.0/
360.0
06-53 Fault Record 1 (Min)
0~65535 minutes
Read Only
06-54 Fault Record 2 (Min)
0~65535 minutes Read Only
06-55 Fault Record 3 (Min)
0~65535 minute Read Only
06-56 Fault Record 4 (Min) 0~65535 minutes
Read Only
06-57 Fault Record 5 (Min) 0~65535 minutes
Read Only
06-58 Fault Record 6 (Min) 0~65535 minutes
Read Only
06-59
Number of Days of
Malfunction (days)
Read Only
Read Only
06-60
Duration of Malfunction
(minutes)
Read Only
Read Only
06-61 Low Current Setting Level 0~100.0% 0
06-62
Low Current Detection
Time
0~360.00 seconds 0
06-63
Options when low current
occurs
0 : No function
1 : Warn and coast to stop
2 : Warn and ramp to stop by 2nd deceleration time
3 : Warn and operation continues
0
06-64 Fire mode
0: No function
1: Forward operation
2: Reverse Operation
0
06-65
Operating Frequency
when running Fire
Mode(Hz)
0.00 to 600.00Hz 600.00
Table 7. Protection Parameters
Parameter Explanation Settings
Factory
Setting
