CHAPTER 12: DESCRIPTION OF PARAMETER SETTINGS
151 63-4528—04
53 Triggered CANopen quick stop
When this function is triggered under CANopen control, the drive will change its
status to quick stop.
UVW magnetic contactor ON/
OFF
To receive confirmation signals while there is UVW magnetic contactor during output.
55
Confirmation signal of released
brake
When a motor has a mechanical brake, this function is to confirm a brake has been
released.
56 Max. Reverse Disabled To set maximum value while Reverse and Forward operations have a limit switch to
do reciprocating actions.
57 Max. Forward Disabled
58
Enable fire mode with RUN
Command
Enable this function under fire mode to force the drive to run (while there is RUN
COMMAND).
59
Enable fire mode without RUN
Command
Enable this function under fire mode to force the drive to run (while there isn’t RUN
COMMAND).
60 Disable all the motors
61 Disable Motor#1
If any of Auxiliary Motor#1 to Motor#8 is out of order or under maintenance, enable
this terminal to bypass that motor.
62 Disable Motor#2
63 Disable Motor#3
64 Disable Motor#4
65 Disable Motor#5
66 Disable Motor#6
67 Disable Motor#7
68 Disable Motor#8
Table 1. Table of Functions (Continued)
