CHAPTER 8: INSTALLATION OF THE OPTION CARDS
63-4528—04 70
I/O Expansion Card
(6 Digital Inputs)
Terminals Descriptions
AC
AC power Common for multi-function input terminal (Neutral)
MI9~ MI14
Refer to Pr. 02.26~ Pr. 02.31 in Chapter 11for multi-function input selection
Input voltage: 100~130VAC
Input frequency: 57~63Hz
Input impedance: 27Kohm
Terminal response time:
ON: 10ms
OFF: 20ms
Relay Expansion Card
Terminals Descriptions
MO3 ~ MO13
Refer to Pr. 02.36~ Pr. 02.46 in Chapter 11 for multi-function output selection
Resistive load:
5A(N.O.)/3A(N.C.) 250VAC
5A(N.O.)/3A(N.C.) 30VDC
Inductive load (COS 0.4)
2.0A(N.O.)/1.2A(N.C.) 250VAC
2.0A(N.O.)/1.2A(N.C.) 30VDC
It is used to output each monitor signal, such as drive is in operation, frequency
attained or overload indication.
Screw Specifications for Option Cards’ Terminals
I/O Extension Card
(4 Digital Input and 4 Digital Output)
Wire Gauge
24~12AWG (0.205~3.31mm
2
)
Torque 4Kg-cm [3.47Ib-in]
I/O Extension Card
(6 Digital Input)
Wire Gauge
24~16AWG (0.205~1.31mm
2
)
Torque 6Kg-cm [5.21Ib-in]
