CHAPTER 8: INSTALLATION OF THE OPTION CARDS
75 63-4528—04
LED Indicators & Troubleshooting
LED Indicators
LED Status Indication Action
POWER Green
On Power supply in normal status No action required
Off No power supply Check if the power supply is plugged.
LINK Green
On Network connection in normal status No action required
Flashes Network in operation No action required
Off Network not connected Check if the network cable is connected
Troubleshooting
Abnormality Cause Action
POWER LED off VFD not powered
Check if VFD is powered, and if the power supply is
normal.
MODBUS TCP/IP
COMMUNICATION CARD not
connected to VFD
Make sure MODBUS TCP/IP COMMUNICATION CARD
is connected to VFD.
LINK LED off
MODBUS TCP/IP
COMMUNICATION CARD not
connected to network
Make sure the network cable is correctly connected to
network.
Poor contact to RJ-45 connector
Make sure RJ-45 connector is connected to Ethernet
port.
No module found
MODBUS TCP/IP
COMMUNICATION CARD not
connected to network
Make sure MODBUS TCP/IP COMMUNICATION CARD
is connected to network.
PC and MODBUS TCP/IP
COMMUNICATION CARD in
different networks and blocked by
network firewall.
Search by IP or set up relevant settings by VFD keypad.
Fail to open MODBUS
TCP/IP COMMUNICATION
CARD setup page
MODBUS TCP/IP
COMMUNICATION CARD not
connected to network
Make sure MODBUS TCP/IP COMMUNICATION CARD
is connected to the network.
Incorrect communication setting in
DCISoft
Make sure the communication setting in DCISoft is set to
Ethernet.
PC and MODBUS TCP/IP
COMMUNICATION CARD in
different networks and blocked by
network firewall.
Conduct the setup by VFD keypad.
Able to open MODBUS
TCP/IP COMMUNICATION
CARD setup page but fail
to utilize webpage
monitoring
Incorrect network setting in
MODBUS TCP/IP
COMMUNICATION CARD
Check if the network setting for MODBUS TCP/IP
COMMUNICATION CARD is correct. For the Intranet
setting in your company, please consult your IT staff. For
the Internet setting in your home, please refer to the
network setting instruction provided by your ISP.
Fail to send e-mail
Incorrect network setting in
MODBUS TCP/IP
COMMUNICATION CARD
Check if the network setting for MODBUS TCP/IP
COMMUNICATION CARD is correct.
Incorrect mail server setting Please confirm the IP address for SMTP-Server.
