Honeywell VFD CORE User Manual

CHAPTER 11: SUMMARIES OF PARAMETER SETTINGS
99 63-4528—04
00-12 Carrier Frequency (KHz)
2~15kHz
230V
Normal duty:
1~20hp
8
Heavy duty:
0.5~15HP
460V
Normal duty:
1~25hp
Heavy duty:
0.5~20HP
2~10kHz
230V
Normal duty:
25~60hp
6
Heavy duty:
20~50hp
460V
Normal duty:
30~100hp
Heavy duty:
25~75hp
2~9kHz
230V
Normal duty:
75~125hp
4
Heavy duty:
60~100hp
460V
Normal duty:
125~536hp
Heavy duty:
100~475hp
00-13
PLC command mask (SOOC,
SOOF)
0~65535
0
Read
Only
a
00-14
Source of the MASTER
Frequency Command (AUTO)
0: Digital keypad
1: RS-485 serial communication
2: External analog input (Pr.03-00)
3: External UP/DOWN terminal
6: CANopen communication card
8: Communication card (no CANopen card)
2
a
00-15
Source of the Opertaion
Command (AUTO)
0: Digital keypad
1: External analog input (Pr.03-00)
2: RS-485 serial communication
3: External UP/DOWN terminal
5: Communication card ( not included CANopen card)
1
a
00-16 Stop method
0: Ramp to stop
1: Coast to stop
1
a
00-17
Motor Operating Direction
Control
0: Enable forward/reverse
1: Reverse disable
2: Forward disable
1
a
00-18
Memory of Communication
Frequency Command
Read Only
Read
Only
00-19 User Defined Property
Bit 0~3: user defined on decimal places
0000b: no decimal place
0001b: one decimal place
0010b: two decimal place
0011b: three decimal place
Bit 4~15: user define on unit
000xh: Hz
001xh: rpm
002xh: %
003xh:kg
0
00-20 Max. User Defined Value
0: Disable
0000b: 0~65535 (No decimal place in Pr.00-19 setting)
0001b: 0.0~6553.5 (One decimal place in Pr.00-19
setting)
0010b: 0.0~655.35(Two decimal place in Pr.00-19 setting)
0011b: 0.0~65.536 (Three decimal place in Pr.00-19
setting)
0
Parameter Function Setting
Factory
Setting
