272 Xenon XP User Guide
File Format - TIFF binary group 4,
compressed
IMGFMT2 221
File Format - TIFF grayscale IMGFMT3 221
File Format - Uncompressed
binary
IMGFMT4 221
File Format - Uncompressed
grayscale
IMGFMT5 221
File Format - BMP IMGFMT8 221
*Histogram Stretch Off IMGHIS0 222
Histogram Stretch On IMGHIS1 222
*Noise Reduction Off IMGFSP0 223
Noise Reduction On IMGFSP1 223
Invert Image around X axis IMGNVX1 222
Invert Image around Y axis IMGNVY1 222
Rotate Image none IMGROT0 223
Rotate Image 90° right IMGROT1 223
Rotate Image 180° right IMGROT2 223
Rotate Image 90° left IMGROT3 223
JPEG Image Quality (0-100) *50 IMGJQF### 224
*Gamma Correction Off IMGGAM0 224
Gamma Correction On (0-1000) IMGGAM### 224
Image Crop - Left (0-843) *0 IMGWNL### 224
Image Crop - Right (0-843) *843 IMGWNR### 224
Image Crop - Top (0-639) *0 IMGWNT### 224
Image Crop - Bottom (0-639)
*639
IMGWNB### 225
Image Crop - Margin (1-238) *0 IMGMAR### 225
Protocol - None (raw) IMGXFR0 225
Protocol - None (default USB) IMGXFR2 225
Protocol - Hmodem Compressed
(default RS232)
IMGXFR3 225
Protocol - Hmodem IMGXFR4 225
*Ship Every Pixel IMGSUB1 226
Ship Every 2nd Pixel IMGSUB2 226
Ship Every 3rd Pixel IMGSUB3 226
*Document Image Filter Off IMGUSH0 226
Document Image Filter On (0-
255)
IMGUSH### 226
*Don’t Ship Histogram IMGHST0 227
Selection
Setting
* Indicates default
Serial Command
# Indicates a numeric
entry
Page
