HP 260 G2 User Manual

4 Removal and replacement procedures
Adherence to the procedures and precautions described in this chapter is essential for proper service. After
completing all necessary removal and replacement procedures, run the Diagnostics utility to verify that all
components operate properly.
NOTE: Not all features listed in this guide are available on all computers.
NOTE: HP continually improves and changes product parts. For complete and current information on
supported parts for your computer, go to http://partsurfer.hp.com, select your country or region, and then
follow the on-screen instructions.
Preparation for disassembly
See Routine care, SATA drive guidelines, and disassembly preparation on page 6 for initial safety procedures.
1. Remove/disengage any security devices that prohibit opening the computer.
2. Remove all removable media, such as a USB ash drive, from the computer.
3. Turn o the computer properly through the operating system, then turn o any external devices.
CAUTION: Turn o the computer before disconnecting any cables.
Regardless of the power-on state, voltage is always present on the system board as long as the system
is plugged into an active AC outlet. In some systems the cooling fan is on even when the computer is in
the “Standby,” or “Suspend” modes. The power cord should always be disconnected before servicing a
unit.
4. Disconnect the power cord from the power outlet and disconnect any external devices.
5. If the computer is on a stand, remove the computer from the stand.
WARNING! Beware of sharp edges inside the chassis.
Preparation for disassembly 13

HP 260 G2 Specifications

General

Tcase	- °C
Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor cache	2 MB
Processor cores	2
Processor family	Intel® Pentium®
Processor series	Intel Pentium 4000 series for Mobile
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Number of QPI links	-
Processor frequency	2.1 GHz
Processor cache type	Smart Cache
Configurable TDP-down	10 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Number of processors installed	1
Maximum number of PCI Express lanes	10
Memory types supported by processor	DDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	- V
Memory clock speeds supported by processor	1866, 2133, 1600 MHz
Memory bandwidth supported by processor (max)	34.1 GB/s
Maximum internal memory supported by processor	32 GB
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 510
Graphics card Open GL support	Yes
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	950 MHz
Number of displays supported (on-board graphics)	3
Processor code	SR2EX
Processor ARK ID	89611
Processor package size	42 X 24 mm
Supported instruction sets	SSE4.1, SSE4.2
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	1 x 4 GB
Sustainability certificates	EPEAT Gold, ENERGY STAR
Power supply	65 W
Audio chip	Realtek ALC221
Product type	Mini PC
Chassis type	Desktop
Product color	Black
Country of origin	China
HDMI version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt 3 ports quantity	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Operating system installed	FreeDOS
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Total storage capacity	500 GB

Weight and Dimensions

Depth	175 mm
Width	177 mm
Height	34 mm
Weight	1050 g
