Page #57 background imageLoading...
Page #57 background image
If you have installed an operating system other than the factory-installed operating system, check to be
sure that it is supported on the system.
If the system has multiple video sources (embedded, PCI, or PCI-Express adapters) installed (embedded
video on some models only) and a single monitor, the monitor must be plugged into the monitor
connector on the source selected as the primary VGA adapter. During boot, the other monitor connectors
are disabled and if the monitor is connected into these ports, the monitor will not function. You can
select which source will be the default VGA source in Computer Setup.
CAUTION: When the computer is plugged into an AC power source, there is always voltage applied to the
system board. You must disconnect the power cord from the power source before opening the computer to
prevent system board or component damage.
Solving general problems
You may be able to easily resolve the general problems described in this section. If a problem persists and you
are unable to resolve it yourself or if you feel uncomfortable about performing the operation, contact an
authorized dealer or reseller.
WARNING! When the computer is plugged into an AC power source, voltage is always applied to the system
board. To reduce the risk of personal injury from electrical shock and/or hot surfaces, be sure to disconnect
the power cord from the wall outlet and allow the internal system components to cool before touching.
Cannot access the Computer Setup (F10) Utility when booting the computer.
Cause Solution
The Computer Setup (F10) Utility is set to “fast boot” causing the
F10 access screen to display too briey when booting the
computer.
Before turning on the computer, press and hold F10. Turn on the
computer and continue to hold F10 until the Computer Setup
(F10) Utility is displayed.
- or –
Follow the Windows instructions for rebooting the computer into
the Computer Setup (F10) Utility.
Computer appears locked up and will not turn o when the power button is pressed.
Cause Solution
Software control of the power switch is not functional.
1.
Press and hold the power button for at least four seconds
until the computer turns o.
2.
Disconnect the power cord from the electrical outlet.
Computer will not respond to keyboard or mouse.
Cause Solution
Computer is in Sleep state. To resume from Sleep state, press the power button.
CAUTION: When attempting to resume from Sleep state, do not
hold down the power button for more than four seconds.
Otherwise, the computer will shut down and you will lose any
unsaved data.
System has locked up. Restart computer.
Solving general problems 49

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 260 G2 and is the answer not in the manual?

HP 260 G2 Specifications

General IconGeneral
Tcase- °C
Bus typeOPI
SteppingD1
Tjunction100 °C
Processor cache2 MB
Processor cores2
Processor familyIntel® Pentium®
Processor seriesIntel Pentium 4000 series for Mobile
Processor socketLGA 1356 (Socket B2)
Processor threads4
Processor codenameSkylake
Number of QPI links-
Processor frequency2.1 GHz
Processor cache typeSmart Cache
Configurable TDP-down10 W
Processor lithography14 nm
Processor manufacturerIntel
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 4x1
Thermal Design Power (TDP)15 W
Number of processors installed1
Maximum number of PCI Express lanes10
Memory types supported by processorDDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM
Memory voltage supported by processor- V
Memory clock speeds supported by processor1866, 2133, 1600 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor32 GB
On-board graphics card ID1916
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 510
Graphics card Open GL supportYes
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency300 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)950 MHz
Number of displays supported (on-board graphics)3
Processor codeSR2EX
Processor ARK ID89611
Processor package size42 X 24 mm
Supported instruction setsSSE4.1, SSE4.2
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Memory slots2x SO-DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)1 x 4 GB
Sustainability certificatesEPEAT Gold, ENERGY STAR
Power supply65 W
Audio chipRealtek ALC221
Product typeMini PC
Chassis typeDesktop
Product colorBlack
Country of originChina
HDMI version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt 3 ports quantity0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Operating system installedFreeDOS
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Total storage capacity500 GB
Weight and Dimensions IconWeight and Dimensions
Depth175 mm
Width177 mm
Height34 mm
Weight1050 g
