Page #71 background imageLoading...
Page #71 background image
There is no sound or sound volume is too low.
Cause Solution
The application is set to use a dierent audio device than
speakers.
Some graphics cards support audio over the DisplayPort
connection (if applicable), so multiple audio devices may be listed
in Device Manager. Make sure the correct device is being used.
To access Device Manager in Windows 7, click Start, select Control
Panel, and then select Device Manager.
To access Device Manager in Windows 10, type device
manager in the taskbar search box, and then select Device
Manager from the list of applications.
Some applications can select which audio output device is used. Make sure the application has selected the correct audio device.
The operating system controls may be set to use a dierent audio
device as the default output device than what is expected.
Set the operating system to use the correct audio device.
Solving printer problems
If you encounter printer problems, see the documentation that came with the printer and to the common
causes and solutions listed in the following table.
Printer will not print.
Cause Solution
Printer is not turned on and online. Turn the printer on and make sure it is online.
The correct printer drivers for the application are not installed.
1.
Install the correct printer driver for the application.
2.
Try printing using the MS-DOS command:
DIR C:\ > [printer port]
where [printer port] is the address of the printer being
used. If the printer works, reload the printer driver.
To run MS-DOS commands, press the Windows key + r, type cmd
in the Open box, and then click OK.
If you are on a network, you may not have made the connection
to the printer.
Make the proper network connections to the printer.
Printer may have failed. Run printer self-test.
Printer will not turn on.
Cause Solution
The cables may not be connected properly. Reconnect all cables and check the power cord and electrical
outlet.
Solving printer problems 63

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP 260 G2 and is the answer not in the manual?

HP 260 G2 Specifications

General IconGeneral
Tcase- °C
Bus typeOPI
SteppingD1
Tjunction100 °C
Processor cache2 MB
Processor cores2
Processor familyIntel® Pentium®
Processor seriesIntel Pentium 4000 series for Mobile
Processor socketLGA 1356 (Socket B2)
Processor threads4
Processor codenameSkylake
Number of QPI links-
Processor frequency2.1 GHz
Processor cache typeSmart Cache
Configurable TDP-down10 W
Processor lithography14 nm
Processor manufacturerIntel
PCI Express slots version2.0
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x4, 4x1
Thermal Design Power (TDP)15 W
Number of processors installed1
Maximum number of PCI Express lanes10
Memory types supported by processorDDR3L-SDRAM, LPDDR3-SDRAM, DDR4-SDRAM
Memory voltage supported by processor- V
Memory clock speeds supported by processor1866, 2133, 1600 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor32 GB
On-board graphics card ID1916
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 510
Graphics card Open GL supportYes
On-board graphics card familyIntel® HD Graphics
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency300 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)950 MHz
Number of displays supported (on-board graphics)3
Processor codeSR2EX
Processor ARK ID89611
Processor package size42 X 24 mm
Supported instruction setsSSE4.1, SSE4.2
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Memory slots2x SO-DIMM
Internal memory4 GB
Memory channelsDual-channel
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Memory layout (slots x size)1 x 4 GB
Sustainability certificatesEPEAT Gold, ENERGY STAR
Power supply65 W
Audio chipRealtek ALC221
Product typeMini PC
Chassis typeDesktop
Product colorBlack
Country of originChina
HDMI version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Thunderbolt 3 ports quantity0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Operating system installedFreeDOS
HDD speed5400 RPM
HDD interfaceSATA
Storage mediaHDD
Total storage capacity500 GB
Weight and Dimensions IconWeight and Dimensions
Depth175 mm
Width177 mm
Height34 mm
Weight1050 g
