System board
NOTE: All system board spare part kits include replacement thermal material.
NOTE: System board appearance may vary.
Description
System board with embedded Intel Core i5-4210U processor
System board with embedded Intel Core i3-4030U processor
System board with embedded Intel Pentium 3558U processor
System board with embedded Intel Celeron 2957U processor
1. Prepare the computer for disassembly (Preparation for disassembly on page 13).
2. Remove the access panel (Access panel on page 14).
3. Remove the memory modules (Memory on page 17).
4. Remove the hard drive (Hard drive on page 15).
5. Remove the drive cage (Drive cage and drive cable on page 28).
6. Remove the WLAN module (WLAN module on page 21).
7. Remove the fan (Fan on page 24).
8. Remove the heat sink (Heat sink on page 27).
9. Disconnect all cables from the system board, noting their location for reinstallation.
10. Remove the four Torx screws (1) that secure the system board to the computer.
30 Chapter 4 Removal and replacement procedures
