13-28
HP Procurve Stack Management
HP Procurve Stack Management
HP Procurve Stack
Management
Using Any Stacked Switch To View the Status for All Switches with
Stacking Enabled. This procedure displays the general status of all switches
in the IP subnet (broadcast domain) that have stacking enabled.
1. Go to the console Main Menu for any switch configured for stacking and
select:
9. Stacking ...
2. Stacking Status (All)
You will then see a Stacking Status screen similar to the following:
Figure 13-18. Example of Stacking Status for All Detected Switches Configured for Stacking
Viewing Commander Status. This procedure displays the Commander and
stack configuration, plus information identifying each stack member.
To display the status for a Commander, go to the console Main Menu for the
switch and select:
9. Stacking ...
1. Stacking Status (This Switch)
You will then see the Commander’s Stacking Status screen:
For status descriptions,
see the table on page
13-48.
