16-5
Spanning Tree Protocol (STP)
CLI: Configuring STP
Spanning Tree Protocol
(STP)
7. When you are finished editing parameters, press [Enter] to return to the
Actions line.
8. Press [S] to save the currently displayed STP parameter settings, then
return to the Main Menu.
CLI: Configuring STP
STP Commands Used in This Section
Viewing the Current STP Configuration. Regardless of whether STP is
disabled (the default), this command lists the switch’s full STP configuration,
including general settings and port settings.
Syntax: show spanning-tree configuration
In the default configuration, STP appears similar to the following:
show spanning-tree config Below
spanning-tree page 16-6
forward-delay <4 - 30> page 16-7
hello-time <1 - 10> page 16-7
maximum-age <6 - 40> page 16-7
priority <0 - 65535> page 16-7
ethernet <port-list> page 16-8
path-cost <1 - 65535> page 16-8
priority <0 - 255> page 16-8
mode <norm | fast> page 16-8
show spanning tree This command lists additional STP monitoring data not
covered in this chapter. See “Spanning Tree Protocol (STP)
Information” on page 17-17
