17-25
Monitoring and Analyzing Switch Operation
Port Monitoring Features
Monitoring and Analyzing
Switch Operation
Figure 17-19. How To Select a Monitoring Port
5. Use the Space bar to select the port to use for monitoring.
6. Use the downarrow key to move the cursor to the Action column for the
individual ports and position the cursor at a port you want to monitor.
7. Press the Space bar to select Monitor for each port that you want moni-
tored. (Use the downarrow key to move from one port to the next in the
Action column.)
8. When you finish selecting ports to monitor, press [Enter], then press [S] (for
S
ave) to save your changes and exit from the screen.
9. Return to the Main Menu.
CLI: Configuring Port Monitoring
Port Monitoring Commands Used in This Section
Move the cursor to the
Monitoring Port parameter.
Inbound Port Monitoring
(Only) on the Switch 4108
show monitor
mirror-port
monitor
below
page 17-26
page 17-27
