HP 5120 series User Manual

79
To do… Use the command… Remarks
Create a basic ACL and enter its
view, or enter the view of an
existing basic ACL
acl [ ipv6 ] number acl-number
[ match-order { config | auto } ]
Required
By default, no basic ACL exists.
Create rules for this ACL
rule [ rule-id ] { permit | deny }
[ source { sour-addr sour-wildcard |
any } | time-range time-name |
fragment | logging ]*
Required
Exit the basic ACL view quit —
Associate this SNMP community
with the ACL
snmp-agent community { read |
write } community-name [ acl
acl-number | mib-view
view-name ]*
Required
You can associate the ACL when
creating the community, the SNMP
group, and the user.
For more information about
SNMP, see the Network
Management and Monitoring
Configuration Guide.
Associate the SNMP group with
the ACL
snmp-agent group { v1 | v2c }
group-name [ read-view
read-view ] [ write-view
write-view ] [ notify-view
notify-view ] [ acl acl-number ]
snmp-agent group v3 group-name
[ authentication | privacy ]
[ read-view read-view ]
[ write-view write-view ]
[ notify-view notify-view ] [ acl
acl-number ]
Associate the user with the ACL
snmp-agent usm-user { v1 | v2c }
user-name group-name [ acl
acl-number ]
snmp-agent usm-user v3
user-name group-name [ [ cipher ]
authentication-mode { md5 | sha }
auth-password [ privacy-mode
{ 3des | aes128 | des56 }
priv-password ] ] [ acl acl-number ]
Source IP-based login control over NMS users configuration
example
Network requirements
As shown in Figure 24, configure the device to allow only NMS users from Host A and Host B to access.
