HP 5120 SI Series

157
NOTE:
• Make sure that the host, switch, and servers can reach each other before portal authentication is
enabled.
• Configure the RADIUS server properly to provide normal authentication/authorization/accounting
functions for users. In this example, you must create a portal user account with the account name userpt
on the RADIUS server, and configure an authorized VLAN for the account.
• On the DHCP server, you must specify the IP address ran
g
es (192.168.1.0/24, 3.3.3.0/24, 2.2.2.0/24),
specify the default
g
ateway addresses (192.168.1.1, 3.3.3.1, 2.2.2.1), exclude the update server's address
2.2.2.2 from the address ran
g
es for address allocation, specify the leases for the assi
g
ned IP addresses
and make sure there is a route to the host. To shorten the IP address update time in case of an
authentication state change, set a short lease for each address.
• Because the DHCP server and the DHCP client are not in the same subnet, you must confi
g
ure a DHCP
relay agent on the subnet of the client. For more information about DHCP relay agent, see
Layer 3—I
P
Services Configuration Guide .
1. Configure portal authentication
# Add Ethernet ports to related VLANs and configure IP addresses for the VLAN interfaces. (Details not
shown)
# Configure PKI domain pkidm, and apply for a local certificate and CA certificate. For more
configuration information, see the chapter "PKI configuration."
# Edit the user-defined authentication pages file, compress it into a zip file named defaultfile, and save
the file in the root directory of the access device.
# Configure SSL server policy sslsvr, and specify to use PKI domain pkidm.
<Switch> system-view
[Switch] ssl server-policy sslsvr
[Switch-ssl-server-policy-sslsvr] pki pkidm
[Switch-ssl-server-policy-sslsvr] quit
# Configure the local portal server to support HTTPS and reference SSL server policy sslsvr.
[Switch] portal local-server https server-policy sslsvr
# Configure the IP address of loopback interface 12 as 4.4.4.4.
[Switch] interface loopback 12
[Switch-LoopBack12] ip address 4.4.4.4 32
[Switch-LoopBack12] quit
# Specify IP address 4.4.4.4 as the listening IP address of the local portal server for Layer 2 portal
authentication.
[Switch] portal local-server ip 4.4.4.4
# Enable portal authentication on port GigabitEthernet 1/0/1, and specify the Auth-Fail VLAN of the
port as VLAN 2.
[Switch] interface gigabitethernet 1/0/1
[Switch–GigabitEthernet1/0/1] port link-type hybrid
[Switch–GigabitEthernet1/0/1] mac-vlan enable
[Switch–GigabitEthernet1/0/1] portal local-server enable
[Switch–GigabitEthernet1/0/1] portal auth-fail vlan 2
[Switch–GigabitEthernet1/0/1] quit
2. Configure a RADIUS scheme
