Triple authentication configuration
This chapter includes these sections:
• Introduction to triple authentication
• Triple authentication configuration task list
• Triple authentication configuration examples
Introduction to triple authentication
Overview
The terminals in a LAN may support different authentication methods. As shown in Figure 71, a printer
supports only MAC authentication, a PC installed with the 802.1X client supports 802.1X authentication,
and the other PC carries out portal authentication. To satisfy the different authentication requirements, the
port of the access device which connects to the terminals needs to support all the three types of
authentication and allow a terminal to access the network after the terminal passes one type of
authentication.
Figure 66 Triple authentication network diagram
The triple authentication solution can satisfy the requirements. It is implemented by enabling portal
authentication, MAC authentication, and 802.1X authentication on a Layer-2 access port. A terminal
connected to that port can access the network after passing a type of authentication.
NOTE:
For more information about portal authentication, MAC authentication, and 802.1X authentication, see
the chapters "Portal configuration," "MAC authentication configuration," and "802.1X configuration."
Triple authentication mechanism
The three types of authentication enabled on an access port are triggered differently.
