HP 54 Basic Cutter User Manual

Welcome to your cutter
Your cutter is a drag-knife contour cutter designed to cut exible substrates accurately. Some major features of
the cutter are shown below:
●
Optical Positioning System (OPOS X) and HP Barcode System for precise and unattended cutting
●
Dierent cutting modes, with the ability to cut completely through some substrates
●
Compatible with blade, pen, and pounce tools
●
High-speed cutting head, for reliable and eortless vinyl cutting
●
Intuitive control panel to modify settings easily
●
Intelligent substrate system to keep substrates on track, even when cutting at top speed
●
Ethernet (LAN) connectivity
●
Substrate basket included
To send print jobs to your printer, you will need Raster Image Processor (RIP) software, which should be run on a
separate computer. RIP software is available from various dierent companies. Included in the box is a license for
the HP FlexiPrint and Cut RIP, supporting Print and Cut and Direct Cut workows.
Cutter models
HP 54 Basic Cutter, HP Latex 54 Cutter, and HP Latex 64 Cutter
Supplied with the cutter HP standard blades (2)
HP cut-o knife
HP 3-in substrate anges
HP FlexiPrint and Cut RIP license
Optional accessories HP Latex Cutter Extended Kit
HP Latex 2-in Media Holder Kit
HP Latex Standard Blade Kit
HP Latex Specialty Blade Kit
Consumables HP Latex Standard Blade Kit
Documentation
The following documents can be downloaded from http://www.hp.com/go/latex115printandcut/manuals/:
●
Introductory information
●
Site preparation guide
●
Assembly instructions
●
User guide
●
Legal information
●
Limited warranty
2 Chapter 1 Introduction ENWW

HP 54 Basic Cutter Specifications

General

Brand	HP
Model	54 Basic Cutter
Category	Plotter
Language	English
