EMU indicator displays
The EMU status indicators are located above the alphanumeric display. See Figure 13 (page 33).
These indicators present the same information as those on the front, lower right corner of the
enclosure.
You can determine the EMU and enclosure status using the information in Table 10 (page 35).
Table 10 EMU status indications
Status and recommended actionsFault indicator
(amber)
Power indicator
(green)
EMU indicator (green)
The EMU Locate function is active. This display
has precedence over all others. Fault conditions
cannot be displayed when the Locate function is
active.
FlashingFlashingFlashing
The EMU is operational. The enclosure power
(both +5 VDC and +12 VDC) is present and
correct. There are no enclosure faults.
OffOnFlashing
The EMU is operational. There is an enclosure
fault. Check the alphanumeric display error code
for information about the problem.
OnOnFlashing
The EMU is operational. This display may be
present when power is initially applied to the
enclosure. Note: When the +5 VDC is incorrect,
all the indicators are off.
OffOffFlashing
There is an EMU fault. There is no enclosure fault.OffOnOn
There is an EMU fault. There is no enclosure fault.OffOnOff
There is an enclosure fault. Either +5 VDC is
incorrect, or both +5 VDC and +12 VDC are
incorrect. Other error conditions may exist.
OffOffOff
Using the alphanumeric display
The two-character alphanumeric display is located at the top of the EMU (see Figure 13 (page
33)). This seven-segment display provides information about multiple enclosure functions. The
push-button control the data displayed or entered.
Alphanumeric display description
The top-level, two-character alphanumeric display (En, Li, rG, Au, and Er), is the display group.
The function of the other displays is display-group dependent. The default display is the enclosure
number, a decimal number in the range 00 through 14. The push-button allow you to select the
alphanumeric display or to enter data.
• The bottom push-button sequentially moves between groups and selects a display group.
See Table 11 (page 36) for a description of these display groups.
• he top push-button moves between the levels within a display group (see 2, Figure 13 (page
33)).
Display groups
When you press and release the bottom push-button, the alphanumeric display selects a different
display group. Table 11 (page 36) describes the display groups.
