Modulation Keys
(PULSE MODE
fi]
Associated SCPI Commands
PULM:SOURce
INTernal
Sets
tha
pulse mode to
internar!
PULM:SOURce
SCALar
Sets the pulse mode to scalar.
PULM:SOURce
EXTernal
Sets the pulse mode to
external
PULM:SOURce
SQIK
Sets the pulse mode to 1
kHz
square wave.
PULM:STATe ON
lbrns
the selected pulse mode on.
PULM:STATe OFF
Turns pulse modulation
ofi
PM1
PM0
MD1
MD0
Associated 8350 Commands
firns
pulse modulation on.
Turns pulse modulation
ofi
Turns square wave modulation on.
Turns square wave modulation
ofi
PEEtIOD
When this function is selected (by pressing (SHIFT) (PULSE MODE
jt))
the pulse
period becomes the active parameter. This parameter applies to the internal
pulse mode.
Its value is shown in the MARKER/SWEEP/STATUS display, in the format
pm-iod=
<diqits><unit.s>.
Units
canbe
ps
orms. The range of
accepted values is 2
,LJS
to 65.53 ms. Resolution is 1
ps.
If necessary, the
pulse width will be decreased to be 1 ps less than the entered period value.
In other words, the period must always be
2
width + 1
ps.
Associated SCPI Commands
PULSe:PERiod
<num>kiuffixl
Sets the pulse period to the desired
value.
10-5
To Next Page
