Getting acquainted
Operating Controls and Indications
1-3
Figure 1-3
Recorder Operating Controls
Table 1-2 Recorder Operating Controls
Control Description
Starts and stops the recorder.
• When the recorder is on, pressing will annotate the
ECG at that point.
• If the recorder is not on and the unit is set up to do so, pressing
will print an ECG strip.
See Appendix A for information about setting up the CodeMaster
XL+ for recording when you press (Record on Mark).
Record button
Mark button
k
k
k
k
