Operating Controls and Indications
1-6
Figure 1-6
SpO
2
Operating Controls
Table 1-5 SpO
2
Operating Controls
Control Description
Turns pulse oximeter on or off.
Activates, selects and deactivates SpO
2
alarms.
SpO
2
input Connector for SpO
2
sensor or sensor adaptor cable.
SpO
2
Input
SpO
2
Alarm button
SpO
2
On/Off button
Sp
O
2
On/
Sp
O
2
