8-1
8Maintaining the Defibrillator
This chapter contains information about maintaining and cleaning the CodeMaster
XL+ defibrillator/monitor.
8Changing the Recorder Paper
Figure 8-1
Changing the Recorder Paper
To change the recorder paper, perform the following steps.
1 Slide the recorder door to the right of the defibrillator as shown in Figure 8-1, on
page 8-1. The paper platen will tilt up.
2 Pull up on the plastic removal tag to remove the empty or low paper roll.
