Monitoring
External Monitoring
3-11
Recorder Errors
The message CHECK RECORDER appears if an error occurs while recording. If this
message appears, check the recorder paper supply. This message may also appear if
the recorder door is open.
3External Monitoring
The ECG output provides an analog 1V/mV ECG signal for connection to an
external monitor. Compatible external monitoring divider cables are listed in Table
3-8, “External Monitoring Cables,” on page 3-11.
The ECG output is also compatible with the interface to the HP central station ECG
input.
Do not use the ECG output to synchronize another defibrillator. (The ECG-In to
ECG-Out delay is 35 milliseconds.)
The connection of external equipment may increase leakage currents. Always
request that local safety personnel verify that multiple connected equipment comply
with local regulatory standards before putting such equipment into service.
Table 3-8 External Monitoring Cables
1000:1 voltage
Divider Cable
Connector
Type
HP Part No.
Six Pin M1782A
Eight Pin M14482A
Twelve Pin M1783A
NOTE
CAUTION
