Monitoring
Recording
3-9
The Event Summary record is cleared each time the defibrillator is turned on and a
new event occurs. This allows you to turn off the defibrillator and return later to
review event information such as code statistics.
Turn the defibrillator off between uses to ensure that Event Summary records are
patient specific.
3Recording
To print a record of the current ECG and of the monitor status, press .
• The upper line of the ECG strip contains a periodic report of monitor parameters
(Date, Time, Heart Rate, ECG Source, ECG Size, and Recorder mode).
• The lower line of the ECG strip records asynchronous events such as Shock deliv-
ery or Heart Rate Alarm violations.
• Several graphic symbols are used to annotate events such as Shock, HR Alarms,
Mark, or Sync.
A 1 mV, 200 ms calibration pulse can be printed on the ECG strip by pressing both
arrows on the key simultaneously.
Appendix A contains a list of configuration settings in setup menu 2 which affect
recorder operation. The recorder can be configured for either monitor or diagnostic
ECG bandwidth data. Delayed (6 seconds) or non-delayed operation is also
configurable.
Automatic Recordings
In setup menu 2, you can enable or disable any of the following automatic
recordings:
• Record on Mark
• Record on Charge
NOTE
