Installation and Setup
Setup
A-10
Time HH:MM Current time
Date DD MMM YY Current date
Armed Tone ON, OFF Beep on Charge done
CRT Alerts ON, OFF Beep on alert message
Alert Volume 3 to 15 Alerts volume
Mode after CV SYNC, DEFIB Specifies mode after cardioversion
Pacer Rate (pacer
option only)
70 (ppm), 40 to 180 in increments of 10 Sets the pacer rate and the initial power-on
default rate.
Pacer Output
(pacer option
only)
30 (mA), 30 to 200 in increments of 10 Sets the pacer current and the initial power-on
default pacer current.
Table 1-2 Setup Menu 2 Settings
Setting Choices Description
Recorder Delay Delay 6s, No Delay Printout is delayed 6 seconds or immediate
Recorder BW Monitor, Diagnostic Bandwidth (recorder only)
Record on Mark ON, OFF Records during mark
Record on Charge ON, OFF Records during charge
Record on Shock ON, OFF Records during discharge
Record on Alarms ON, OFF Records during alarms.
Post Shock Data ON, OFF ON prints the delivered energy statistics.
OFF prints Energy Select control setting.
Power On Lead PADDLES, LEAD I, LEAD II, LEAD III Sets the ECG monitoring source that
appears when you turn on the instrument.
Patient Cable 3 WIRE, 5 WIRE
Notch Filter 60 HZ, 50 HZ, ON, OFF
Table 1-1 Setup Menu 1 Settings
Setting Choices Description
